The HIKMICRO Falcon FH25 is equipped with a highly sensitive detector with a resolution of 384 x 288 (12µm technology) and an OLED display of 1024 x 768 pixels. The built-in sensor with a sensitivity of 20mk and the completely newly developed image optimization software Image Pro offer you a perfectly clear image with an impressive detail resolution even in complete darkness – even under the most demanding weather conditions with only minimal temperature differences between thermal object and environment. This allows you to visualize even the smallest details, such as branches or leaves but also physical features needed for accurate targeting.
Note: The Monocular lens must not be exposed to direct Sunlight, read all instructions before use.
FEATURES
384 x 288 resolution with a 12µm sensor
High sensitivity thermal module NETD <20mK (@25º, F# = 1.0)
Replaceable and rechargeable Li-ion battery
Up to 7 hours of continuous operation
Leading thermal image processing technology: Image Pro
1,024 x 768 resolution 0.39-inch OLED display
SPECIFICATIONS
Image Sensor: VOx uncooled focal plane arrays
Resolution: 384 x 288
Frame Rate: 50Hz
Pixel Interval: 12µm
Response Waveband: 8µm to 14µm
NETD: =20 mK (@25°C), F#=1.0
Focal Length: 25mm
Field of View: 10.5° x 7.9° (H x V)
Aperture: F1.0
Focusing Distance: 2.5m
Optical Magnification: 2.17
Detection Range: 1200m
IMAGE DISPLAY
Monitor: 0.39-inch, OLED, 1,024 x 768
FFC (Flat Field Correction): Auto, manual, external correction
Palettes: Black hot, White hot, Red hot, Fusion
SYSTEM
Storage: Built-in memory module (64GB)
Record Video: Yes
Capture Snapshot: Yes
Standby Mode: Yes
Wi-Fi Hot Spot: Yes
Hot Track: Yes
POWER SUPPLY
Power: 5V, 1.75W
Battery Type: Replaceable and rechargeable Li-ion battery
Battery Operating Time: 7 hours continuous running with CVBA and hotspot function off (25°C)
GENERAL
Working Temperature: -30°C to 55°C; Humidity: 90% or less
Protection Level: IP67
Dimension: 187.7 x 58.3 x 65.2mm
Weight: 500g
PACKING INCLUDES
HIKMICRO Falcon FH25 Handheld Thermal Monocular Camera
1 x USB Cable
1 x Protective Bag
1 x Wrist Strap
1 x Carrying Case
1 x Charger
2 x Cell
1 x Neck Straps
1 x Non-dust Cloth
1 x Quick Start Guide
