25mm Effective objective lens diameter
3.1mm Exit pupil diameter
17mm Exit pupil distance
110m/1000m Field of view at m/1,000 m / ft/1,000 yds
6.8 ° Field of view degrees
6.8 ° Field of view with eye glasses (%)
52 ° Field of view apparent
2.5m Shortest focusing distance
± 5 dpt Diopter adjustment
6 dpt Diopter correction at 8
88% Light transmission
50-74mm Pupil distance
14.2 Twilight factor acc. to ISO 14132-1
110mm Length in mm.
98mm Width in mm.
46mm Height in mm.
-25 to +55 °C Functional temperature
-30 to +70 °C Storage temperature
13 ft / 4 m water depth (inert gas filling) Submersion tightness
